PHS5 Female Thread Rod End Bearing (M5x0.8 / 5mm Bore Heim Joint)

Model: PHS5
  • Delivers high torque density in a compact diameter design
  • Precision gear structure ensures smooth & ultra-low noise operation
  • Wide output speed range to meet versatile industrial needs
  • Fully customizable gear ratios, shaft dimensions, and wire leads
  • Heavy-duty industrial grade quality with long operational lifespan

Product Highlights

  • Standard metric M5x0.8 internal female thread with 5mm spherical bore diameter
  • Carbon steel body with protective zinc plating delivering excellent corrosion resistance
  • GCr15 high-carbon chromium steel spherical ball, precision heat-treated and hard chrome plated
  • Bronze race / PTFE composite insert providing smooth sliding and maintenance-free self-lubrication
  • Large angular misalignment capacity (13°) for high-articulation linkage mechanisms
  • High radial dynamic load rating up to 5.7 kN with high shock resistance
  • Available in both right-hand standard thread (PHS5) and left-hand thread (PHSL5)
  • Full RoHS and REACH environmental compliance across all manufacturing processes

Applications

  • > Micro Motors & Cooling Fans
  • > Precision Testing Instruments
  • > Medical Diagnostic & Imaging Devices
  • > Automotive Steering & Chassis Systems
  • > Fitness & High-End Sports Gear
  • > Textile & Garment Machinery
  • > High-Precision Spindles & CNC Units
  • > Material Handling & Conveyor Rollers
  • > Optical Encoders & Gimbal Systems

Technical Specifications

Parameters Specifications
System of Measurement Metric
Bore Diameter 5mm
Ball Stud Thread Size M5
Outer Diameter 12mm
Ball Diameter 16mm
Ball Material Chrome Steel
Material Carbon Steel
Precision Rating P0
Lubrication Method Self-Lubricating
Industry Certification ISO 9001 Certification
Finish zinc coated
Eye Inside Diameter 5mm
Ball Stud Thread Length 10 mm
Hole Center-to-end Length 27mm
Eye Thickness 8mm
Head Width 16mm
Eye Outside Diameter 12mm

Dimensions & Technical Drawings

PHS5 Female Thread Rod End Bearing (M5x0.8 / 5mm Bore Heim Joint) Dimension Drawing 1
Click to Zoom (Drawing 1)
