2838 Brushless DC Motor Built-in Driver Board 6-Wire PWM Speed Control CW/CCW Brake Tach Output 28x38mm Silent

Nytt

2838 Brushless DC Motor Built-in Driver Board 6-Wire PWM Speed Control CW/CCW Brake Tach Output 28x38mm Silent

Modell: 2838 BLDC

Commutation: Brushless
Rated Power: 10-30W
Speed(RPM): 6000 RPM
Efficiency: IE3
Type: Brushless Motor

Product Highlights

Commutation – High precision engineered commutation (Brushless)
Rated Power – High precision engineered rated power (10-30W)
Speed(RPM) – High precision engineered speed(rpm) (6000 RPM)
Efficiency – High precision engineered efficiency (IE3)
Type – High precision engineered type (Brushless Motor)
Construction – High precision engineered construction (Permanent Magnet)

Applications

> Precision Robotics & Cobots
> Medical Devices & Surgical Systems
> Aerospace & Flight Actuators
> Automotive Electric Drive Systems
> Industrial Automation & AGV/AMR
> Semiconductor Handling Equipment
> CNC Machine Tool Feeding Units
> Precision Optical Positioning
> High-Speed Packaging Machinery

Tekniska specifikationer

Parametrar	Tekniska specifikationer
Kommutering	Borstlös
Nominell effekt	10-30W
Varvtal (RPM)	6000 RPM
Effektivitet	IE3
Typ	Brushless Motor
Byggnad	Permanent Magnet
Frame	--
Motor Mounting Type	Panel Mount
Protect Feature	Totally Enclosed
Usage	Boat, Car, Cosmetic Instrument, Electric Bicycle, Fan, Home Appliance, Smart Home, Electronic automatic lock
Warranty	1 year
Kontinuerlig ström (A)	76mA
Modellnummer	2836
Ursprungsort	Guangdong,China
Varumärke	WYOO
Voltage	12-24V
Speed	6000RPM (PWM100%)
No load Current	76mA (PWM100%)
Shaft Diameter	2,3 mm
Shaft Length	15 mm
Overcurrent Protection	2A
Stall Protection	3S
Max Power	4.8W
Max Efficiency	63.4%
Ansökan	White Home Appliances, Industrial Equipment, Agitators, Valves, Brakes
Försäljningsenheter	Enstaka artikel
Storlek på en enskild förpackning	15X10X8 cm
Bruttovikt per styck	0,05 kg
